Rigging Screw Turnbuckles

Rigging Screw Turnbuckles

WLL
(m.t) 		Dimensions(mm)
Dia
Screw
A 		Length
of Body
B 		Dia of Body
C 		D E Weight
(lbs)
JAW OVALEYE
Length Inside
Dia DiaPin Length Hidth Dia "Length Hidth
D1 D2 D3 D4 E1 E2 E3
0.1 6 102 12 3 5 15 7 6 15 8 0.24
0.15 88 110 15 4 6 16 9 7 19 10 0.5
0.375 10 152 21 5 8 21 11 8 25 11 0.62
0.5 12 175 27 6 10 25 13 11 30 14 1.76
0.75 16 229 27 10 12 40 18 14 41 16 3.09
1.125 20 229 33 12 16 45 20 16 51 22 4.41
1.6 22 305 33 15 18 48 24 16 51 22 7.72
2 24 325 42 16 22 65 28 19 57 25 8.81
2.75 28 356 48 18 22 59 30 19 57 28 9.92
3.75 33 381 48 20 27 62 34 22 65 35 14.3
4.25 35 381 60 22 28 68 38 22 65 36 17.64
5 39 406 60 24 33 74 42 25 74 38 24.25
